Debug, Tweak and fine-tune your DIY electronics projects

This hands-on guide shows, step by step, how to build, debug, and troubleshoot a wide range of analog electronic circuits. Written by electronics guru Ronald Quan, Troubleshooting Electronic Circuits: A Guide to Learning Analog Circuits clearly explains proper debugging techniques as well as testing and modifying methods. In multiple chapters, poorly-conceived circuits are analyzed and improved. Inside, you will discover how to design or re-design high-quality circuits that are repeatable and manufacturable.

Coverage includes:

• An introduction to electronics troubleshooting

• Breadboards

• Power sources, batteries, battery holders, safety issues, and volt meters

• Basic electronic components

• Diodes, rectifiers, and Zener diodes

• Light emitting diodes (LEDs)

• Bipolar junction transistors (BJTs)

• Troubleshooting discrete circuits (simple transistor amplifiers)

• Analog integrated circuits, including amplifiers and voltage regulators

• Audio circuits

• Troubleshooting analog integrated circuits

• Ham radio circuits related to SDR

• Trimmer circuits, including the 555 chip and CMOS circuits
