From Code to Chip
Av Harald Pretl, Jakob Ratschenberger, 2025.Del av serien Synthesis Lectures on Engineering, Science, and Technology.
Open-Source Automated Analog Layout Design
This book shows how the layout of an analog circuit can be automatically generated in a fully open-source way. Based on an exemplary design flow, it introduces and explains the necessary steps for transforming a SPICE netlist into a layout, which can be inspected by the open-source layout editor Magic VLSI. This is done by using the industry?s first open-source process design kit SKY130. Furthermore, the implementation of the design flow in the programming language Python is available as open-source on GitHub.
???????
Ikke tilgjengelig for Klikk&Hent
Midlertidig tomt på lager
Bestillingsvare. Forventes sendt om ca 20 dager
